| 刀片基本形状the basic shape of inserts | 型号 type | 基本尺寸dimension（mm） | ||||
| φi.c | s | φd | r | |||
 | wnmg | 060404-md | 9.525 | 4.76 | 3.81 | 0.4 |
| 060408-md | 9.525 | 4.76 | 3.81 | 0.8 | ||
| 060412-md | 9.525 | 4.76 | 3.81 | 1.2 | ||
| 080404-md | 12.7 | 4.76 | 5.16 | 0.4 | ||
| 080408-md | 12.7 | 4.76 | 5.16 | 0.8 | ||
| 080412-md | 12.7 | 4.76 | 5.16 | 1.2 | ||
更多产品及牌号推荐，欢迎咨询下载。
for more types and grade recommendation, welcome to contact us or download catalog.
