| 刀片基本形状the basic shape of inserts | 型号 type | 基本尺寸dimension（mm） | ||||
| φi.c | s | φd | r | |||
 | snmg | 090304-md | 9.525 | 3.18 | 3.81 | 0.4 |
| 120404-md | 12.7 | 4.76 | 5.16 | 0.4 | ||
| 120408-md | 12.7 | 4.76 | 5.16 | 0.8 | ||
| 120412-md | 12.7 | 4.76 | 5.16 | 1.2 | ||
| 150608-md | 15.875 | 6.35 | 6.35 | 0.8 | ||
| 150612-md | 15.875 | 6.35 | 6.35 | 1.2 | ||
更多产品及牌号推荐，欢迎咨询下载。
for more types and grade recommendation, welcome to contact us or download catalog.
