| 刀片基本形状the basic shape of inserts | 型号 type | 基本尺寸dimension（mm） | |||||
| φi.c | s | φd | r | α | |||
 | dcmt | 070202-fw | 6.35 | 2.38 | 2.8 | 0.2 | 7° |
| 070204-fw | 6.35 | 2.38 | 2.8 | 0.4 | 7° | ||
| 11t302-fw | 9.525 | 3.97 | 4.4 | 0.2 | 7° | ||
| 11t304-fw | 9.525 | 3.97 | 4.4 | 0.4 | 7° | ||
| 11t308-fw | 9.525 | 3.97 | 4.4 | 0.8 | 7° | ||
更多产品及牌号推荐，欢迎咨询下载。
for more types and grade recommendation, welcome to contact us or download catalog.
