| 刀片基本形状the basic shape of blade | 型号 type | dimension（mm）基本尺寸 | ||||
| φi.c | s | φd | r | |||
 | cnmm | 120408-rb | 12.7 | 4.76 | 5.16 | 0.8 |
| 120412-rb | 12.7 | 4.76 | 5.16 | 1.2 | ||
| 120416-rb | 12.7 | 4.76 | 5.16 | 1.6 | ||
| 160608-rb | 15.875 | 6.35 | 6.35 | 0.8 | ||
| 160612-rb | 15.875 | 6.35 | 6.35 | 1.2 | ||
| 160616-rb | 15.875 | 6.35 | 6.35 | 1.6 | ||
| 190612-rb | 19.05 | 6.35 | 7.93 | 1.2 | ||
| 190616-rb | 19.05 | 6.35 | 7.93 | 1.6 | ||
| 190624-rb | 19.05 | 6.35 | 7.93 | 2.4 | ||
| 250724-rb | 25.4 | 7.94 | 9.12 | 2.4 | ||
| 250924-rb | 25.4 | 9.52 | 9.12 | 2.4 | ||
更多产品及牌号推荐，欢迎咨询下载。
for more types and grade recommendation, welcome to contact us or download catalog.
